Drilling Depth Capabilities

Water Well & Reverse Circulation

XPLOM's Water Well and RC fleet delivers high-productivity drilling across a broad depth range, supporting water supply, mineral exploration and resource definition programmes.

Horizontal RC Drainage Drilling

XPLOM's subhorizontal RC fleet is purpose-engineered for near-horizontal drainage and dewatering applications, delivering precision directional capability in demanding mine environments.

Diamond Core Drilling

XPLOM's diamond core fleet covers surface and underground applications, delivering high-quality core recovery across a wide range of depths and rod sizes.

Manufacturer	Model	Application	PQ (ft)	HQ (ft)	NQ (ft)	BQ (ft)
	CT20	Diamond Core – Surface	3,461 ft	5,249 ft	8,038 ft	—
	Christensen C140	Diamond Core – Surface	1,558 ft	2,625 ft	3,937 ft	—
	LM PQ	Diamond Core – Surface & Underground	984 ft	2,297 ft	2,953 ft	—
	LM 110	Diamond Core – Surface & Underground	1,312 ft	1,312 ft	1,312 ft	3,773 ft
	DE 712	Diamond Core – Surface	1,427 ft	2,493 ft	3,609 ft	—
	LF 90	Diamond Core – Surface	1,345 ft	2,369 ft	3,491 ft	—
	DE 710	Diamond Core – Surface	1,083 ft	2,231 ft	3,281 ft	—

* Maximum depth values are indicative and subject to geological conditions, tooling configuration and project-specific requirements. All depths shown in feet.
